Indium FLUXWV-84254-1GL

3590-T Flux - 1 Gallon No-Residue, low solids, non-halide, rosin/resin-free

  • Manufacturer: Indium
  • Model # FLUXWV-84254-1GL
  • Pemro # IND-1360
  • $ 70.52/each
  • Available to Order

Minimum order quantity is 12

Must order in multiples of 4

Add to List

3590-T is a low solids, non-halide, rosin/resin-free flux designed to eliminate post-cleaning operations. The effective flux activators provide superior solderability of surface mount, mixed technology, and through-hole electronic assemblies.

3590-T has a wide process window with excellent wetting capabilities, leaving no residue and high surface insulation resistance.

Features
• Meets Bellcore specification TR-NWT-000078
• Meets IPC J-STD-004 flux type ORL0
• Eliminates the need for cleaning
• Excellent wetting and solderability
• Compatible with conformal coatings without cleaning
• Will not interfere with pin testing

Physical Properties
Color: Clear
Specific Gravity @ 25°C (77ºF): 0.801
Specific Gravity @ 15.5°C (60ºF): 0.808
Acid Value: 16.0
Solids Content: 1.85
Flash Point (ºF TCC): 84
J-STD-004 Flux Type: ORL0
